Prekės aprašymas
6 ports, 4 PoE ports switch UTEPO UTP6306S-PSB
Specifikacijos
SKU
U-3019850
Prekės kodas
SWITCHUTP6306S-PSB
Tiekėjo prekės aprašymas
- 4*10/100/1000 Base-T PoE RJ-45 ports
- 2*1000 Base-X SFP ports
- 1*RJ-45 console port
- Working temperature: -40℃~75℃
- Redundant power supply
- 8kV contact discharge, 12kV air discharge ESD protection
- Fan-less metal shell design
- DIN-rail installation
- General
- ItemsUTP3306TS-PSD
- Downlink Port4*10/100/1000 Base-T PoE++ RJ-45(Auto-MDI/MDI-X)
- Uplink Port1*10/100/1000 Base-T RJ-451*1000 Base-X SFP
- Led Indicators1*PWR, power supply indicators1*Link/Act, SFP port state indicators
- Dimensions (W*D*H)294mm*180mm*44mm
- Input Voltage100~240V AC, 50~60Hz
- Power Consumption≤370W (Full load including PoE)
- MaterialMetal shell
- InstallationRack/Desktop/Wall mounted
- StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
- Forwarding ModesStore and Forward
- MAC Table2k, support auto learning
- Switching Capacity12Gbps/non-blocking
- Packet Forwarding Rate8.928Mpps
- Port Buffer1MB
- Jumbo Frame9716 Bytes
- PoE StandardIEEE 802.3af/at/bt
- PoE Power Supply TypeEnd-span
- PoE Pin Assignment3/6/4/5(+), 1/2/7/8(-)
- PoE Budget90W max for each port, 360W max for whole switch
- Operating-10℃~50℃, 5%~95% (Non-condensation)
- Storage-40℃~70℃, 5%~95% (Non-condensation)
- CertificationsCE, FCC
- System InformationSystem, Hardware, Time and Firmware
- IP StatusIP Interfaces, IP Routes and ARP Table
- SysLogSystem Log Information
- Detailed SysLogID and Message
- MAC TableMAC Address Table: Type, VLAN, MAC Address, CPU and Port Number
- VLANsMembership and Ports
- PortsTraffic Overview and Detailed Statistics
- LACPSystem Status, Port Status and Port Statistics
- Thermal ProtectionThermal Protection Port Status
- Green EthernetPort Power Savings Status
- PoE StatusPower Over Ethernet Status
- LLDPThermal Protection Port Status
- Loop ProtectionLoop Protection Status
- Spanning TreeBridge Status, Port Status and Port Statistics
- IGMP SnoopingIGMP Snooping Status, Groups Information and IPv4 SFM Information
- MLD SnoopingMLD Snooping Status, Groups Information and IPv6 SFM Information
- DHCPServer, Snooping Table, Relay Statistics and Detailed Statistics
- SecurityPort Security, Access Management Statistics, 802.1X, ACL Status and AAA
- QoSQoS Statistics and QCL Status
- IP ConfigIP Configuration, IP Interfaces and IP Routes
- IP StatusIP Interfaces, IP Routes and ARP Table
- DHCP ServerDHCP Server Mode Configuration, Excluded IP and Pool
- NTPNTP Configuration
- TimezoneSystem Timezone Offset and UTC time
- SNMPSystem, Trap, Communities, Users, Groups, Views and Access
- SysLogSystem Log Configuration
- PortsPort Configuration
- AggregationStatic and LACP
- MirroringMirror and Mirror Port Configuration
- Thermal ProtectionThermal Protection Configuration
- Green EthernetPort Power Savings and Port Configuration
- DDMDDM Configuration, DDM Overview and DDM Detailed
- PoE SettingPower Over Ethernet, PoE Power Supply and PoE Port Configuration
- PoE StatusPower Over Ethernet Status
- MAC TableAging Configuration, MAC Table Learning and Static MAC Table Configuration
- PTPPTP Clock Configuration and PTP Status
- VLANsGlobal VLAN and Port VLAN Configuration
- Voice VLANVoice VLAN Configuration and Voice VLAN OUI Table
- GVRPGVRP Global and Port Configuration
- Port IsolationPort Group and Port Isolation
- Loop ProtectionGeneral Settings and Port Configuration
- Spanning TreeBridge Settings, MSTI Mapping, MSTI Priorities, CIST Ports and MSTI Ports
- IPMC ProfileProfile Table and Address Entry
- MEPMaintenance Entity Point
- ERPSEthernet Rapid Ring Protection Switching
- IGMP SnoopingBasic Configuration, VLAN Configuration and Port Filtering Profile
- IPV6 MLD SnoopingBasic Configuration, VLAN Configuration and Port Filtering Profile
- LLDPLLDP Parameters and LLDP Interface Configuration
- UsersUsers Configuration
- Privilege LevelsPrivilege Level Configuration
- SSHSSH Configuration
- HTTPSHTTPS Configuration
- Port Security LimitSystem and Port Configuration
- Access ManagementAccess Management Configuration
- 802.1XNetwork Access Server Configuration
- ACLPorts, Rate Limiters and Access Control List
- ARP InspectionPort Configuration, VLAN Configuration, Static Table and Dynamic TableAAA RADIUS and TACACS+
- Port ClassificationQoS Ingress Port Classification
- Port PolicingQoS Ingress Port Policers
- Queue PolicingQoS Ingress Queue Policers
- Port SchedulerQoS Egress Port Schedulers
- Port ShapingQoS Egress Port Shapers
- Port Tag RemarkingQoS Egress Port Tag Remarking
- Port DSCPQoS Port DSCP Configuration
- DSCP-Based QoSDSCP-Based QoS Ingress Classification
- DSCP TranslationDSCP Translation
- DSCP ClassificationDSCP Classification
- QoS Control ListQoS Control List Configuration
- Storm PolicingGlobal Storm Policer Configuration
- PingICMP Ping
- Cable DiagnosticsCable Status
- CPU LoadCPU Load Information
- Restart DeviceRestart the Device
- Factory DefaultsFactory Defaults
- Firmware UpgradeSoftware Upload
- Firmware SelectSoftware Image Selection
- ConfigurationDownload, Upload, Activate and Delete
Tiekėjo specifikacijos
Product code
SWITCHUTP6306S-PSB
Category
Swit
Supplier's product code
SWITCHUTP6306S-PSB
Product ID
U-3019850
Tiekėjo pateikiama informacija apie prekę gali skirtis nuo realaus produkto. Jei pastebėjote neatitikimų praneškite apie tai el. paštu [email protected].
