Rocker switch; ON-OFF, fixed, 2pins. 6A/250Vac, 19x12mm, SPST, waterproof, orange
Product Code: KE/MI/2F/Y/H/0
More similar products
Pickup at the LEMONA electronics store within 2 hours (if the item is in the store and the order is placed before 3 p.m.)
 6 pcs | Vilnius Žirmūnai Store |
| 6 pcs | Vilnius Naujamiestis Store |
| 1 pcs | Kaunas Store |
 Not available | Klaipėda Store |
| Not available | Šiauliai Store |
| Not available | Central Warehouse (new location) |
Home delivery in Lithuania 1-2 b.d.
Delivery to pickup location 1-2 b.d.
Delivery terms
Pickup In Store
Pickup In Store For free
Orders are processed and shipped on weekdays from 8:00 a.m. to 5:00 p.m.
When your order is ready for collection, we will inform you by SMS and e-mail.
Quantity in shop
| 6 pcs | Vilnius Žirmūnai Store |
| 6 pcs | Vilnius Naujamiestis Store |
| 1 pcs | Kaunas Store |
| Not available | Klaipėda Store |
| Not available | Šiauliai Store |
| Not available | Central Warehouse (new location) |
Home delivery in Lithuania
Home delivery in Lithuania
After handing over the goods to the courier, we will inform you by e-mail. If you are ordering outside of Lithuania please use www.lemona-electronics.eu to order.
Over €30.00 (Orders up to 1000 kgs) | For free |
To €30.00 (Orders up to 3 kgs) | €2.99 |
To €30.00 (Orders up to 1000 kgs) | €3.59 |
Delivery to a DPD Pickup location
Delivery to a DPD Pickup location
After handing over the goods to the courier, we will inform you by e-mail. Orders over €30.00 are delivered free of charge.
€1.99
Product description
Weight
0.02 kg.
Technical data
| Rated current, voltage | 6A 250V AC |
| Contact resistance | ≤50mΩ |
| Insulation resistance | ≥100MΩ |
| Dielectric strength | 1500VAC/5s |
| Endurance | 50000 cycles |
| Ingress protection ratio | IP65 |
Specifications
SKU
376288
Weight
0.02 kg.
Fixation, 1-Su / 0-Be
With
Switch shape
Rectangle
Connection type
ON-OFF
Key color
Yellow
Contact configuration
SPST
Number of contacts
2
Body color
Black
Current, A
6
Product code
KE/MI/2F/Y/H/0
Rated voltage AC, V
250
