Product description
Features
1. IP65 rating, 2m drop proof, CAT III 1000V, CAT IV 600V
2. Large 6000-count LCD screen
3. 5 times/s sampling rate
4. True RMS
5. ACV 750V 5kHz bandwidth
6. (AC+DC) or (AV+FREQ) and more, dual modes
7. Flashlight
8. Auto LCD backlight controlled by light sensor (feature can be turned off)
9. LoZ voltage test, for ghost voltage measurement
10. Motor phase sequence measurement with 2 probes
11. 20A current measurement (max 30 seconds)
12. 31 analogue bar
13. Low pass filter, 1kHz 3dB attenuation
| Specifications | Range | Best Accuracy |
| DC voltage | 600mV ~ 1000V | ±(0.5%+3) |
| AC+DC | 6.000V ~ 600V | ±(1.5%+4) |
| AC voltage | 600mV ~ 750V | ±(0.7%+3) |
| LoZ ACV | 600.0V | ±(2.0%+3) |
| DC current (A) | 600.0μA ~ 20A | ±(0.8%+3) |
| AC current (A) | 600.0μA ~ 20A | ±(1.0%+3) |
| Resistance (Ω) | 600.0Ω ~ 60.00MΩ | ±(0.8%+2) |
| Capacitance | 6.000nF ~ 60.00mF | ±(3%+5) |
| Frequency | 60.00Hz ~ 40.00MHz | ±(0.1%+4) |
| Duty ratio | 0.1% ~ 99.9% | ±(2.0%+5) |
| Peaks hold | 250μS | |
| Features | ||
| Display count | 6000 | |
| Display interface (HTN) | Dual display | |
| Measuring digit conversion rate | times/s | 5 |
| Measuring analogue bar conversion rate | times/s | 20 |
| Analogue bar | 31 section | √ |
| True RMS | √ | |
| AC voltage frequency response | 45 ~5kHz | |
| AC current frequency response | 45 ~5kHz | |
| Low pass filter test | √ (1kHz 3dB attenuation) | |
| Diode/Continuity test | 3V | |
| Auto/Manual range | √ | |
| Auto power off | √ | |
| Continuity buzzer | √ | |
| Low battery indication | √ | |
| Data hold | √ | |
| MAX/MIN | √ | |
| Functional selection | √ | |
| Electrical torch | √ | |
| Auto backlight | √ | |
| Working temperature | 0 °C ~40 °C | |
| 2m drop proof | √ | |
| Protection grade | IP65 | |
| General Characteristics | ||
| Power supply | 9V 6F22 carbon-zinc or 6LR61 alkaline battery | |
| LCD size | 66mm × 51mm | |
| Device weight | 473g | |
| Device size | 195mm × 95mm × 58mm | |
| Standard accessories | testing probes, battery, carrying bag | |
