Product description
Connector: wire-board; socket; male; PIN: 8; straight; THT; 2.54mm NINIGI
Useful information
Specifications
Supplier product description
Connector: wire-board; socket; male; PIN: 8; straight; THT; 2.54mm
Useful information
Supplier parameters
Product code
NCDW-08
Supplier's product code
NCDW-08
Product ID
U-272568
A dimension
17.78mm
B dimension
22.87mm
Connector
socket
Connector pinout layout
1x8
Contact plating
tinned
Contacts pitch
2.54mm
Electrical mounting
THT
Enclosure material
polyamide
Flammability rating
UL94V-0
Kind of connector
male
Locking system
latch
Manufacturer
NINIGI
Max. contact resistance
:20mΩ
Max. operating voltage
250V
Maximum current
2.5A
Number of pins
8
Operating temperature
-25...85°C
Spatial orientation
straight
Type of connector
wire-board
Brand
NINIGI
